Sparkring co-works with several companies to develop fancy products. TI DaVinci DM355/335 multimedia processor has an ARM926EJS core and MPEG4 encoder/decoder in 720p HD. The low cost solution can provide customers a solution to build fancy OSD and the abilty to record and play video signals. Since the cost of small panels drop rapidly, the feasibility of applying color LCD panels to equipments is increased dramatically. It enables the manufacturers to upgrade their producst in different ways.
We can provide the software integration services to our customers. If the customers need both hardware design and software customerization, we can provide the total soltuion with our close hardware parnters. Other TI solution, such as DM64XX series and OMAP series can also be supported by our software team and partners.
If you need further information, please do not hestitate to contact with us.
| MPEG4 Recordable Monitor , SP-201 | |
| CPU | TI DM355/335, ARM926EJS, 135,216, 270MHz |
|---|---|
| RAM | 128MB |
| Flash | 32MB-2GB NAND |
| USB | USB 2.0 GTG X 1 |
| Ethernet | 10/100 M |
| SD | SD X 2 |
| Video Input | NTSC or CMOS/CCD |
| Video Output | NTSC or LCD |
| Video Codec | MPEG4 Encoder/Decoder (up to 720p) |
| Audio I/O | Stereo |
| Audio Codecr | G711, MP3, WMA, AAC |
| I/O | UART X 2, SPI X 1, GPIO |
| O.S. | Linux, WinCE |
